Description

The DS3820AIPA1A1A is an ANA 10 module for the Speedtronic Mark IV series from General Electric.The DS3820AIPA1A1A has thirteen blue masculine connection terminals. Twelve of the masculine terminal ports have twenty metal pins inside, the thirteenth male terminal port is a bit smaller with only ten metal pins inside. The DS3820AIPA1A1A has four white plastic male terminal ports. These male terminal ports have anywhere from two to four gold colored metal pins. The DS3820AIPA1A1A has a feminine terminal port. It is small and red with only two openings. The DS3820AIPA1A1A has around seventy teal diodes. Diodes only allow energy to move in one direction around the circuit board. The DS3820AIPA1A1A has seven large black rectangles with twenty-six metal tabs on the top of each rectangle. The DS3820AIPA1A1A has four metal fasteners. These fasteners are spaced in between the black rectangles. Each metal fastener has two screws one on each end to secure the circuit board in place. There is also a thin metal edge (on the opposite side of the metal fasteners) that have twopre-drilled anchor or screw hole to assist in installation. The DS3820AIPA1A1A also has several screws around the perimeter of the circuit board. The DS3820AIPA1A1A has nearly one-hundred resistors. The resistors have multiple colored rings that indicate the amount of energy the resistor is capable of withstanding.

For additional information please call TurbineIndustrial’s knowledgeable staff.

** Technical support for the DS3820AIPA1A1A was initially provided by General Electric. TurbineIndustrial suggests referring to the original manufacturer's manual for all safety and installation methods.
