Description

General Electric’s DS3800NVIA1G1C is a circuit board that is a part of the Mark IV Speedtronic series. Each item on the circuit board is clearly labeled with a number and letter code. The DS3800NVIA1G1C has letters A through H and the letter J as well as the part number (DS3800NVIA1G1C) and General Electric’s logo. The DS3800NVIA1G1C has one large beige capacitor, four average beige capacitors, and two little beige capacitors. The DS3800NVIA1G1C has twelve metal sticks. The DS3800NVIA1G1C also has three scarlet boxes with metal toggle switches. The DS3800NVIA1G1C has a large black female port along one edge and one smaller blue female port closer to the center of the circuit board. The DS3800NVIA1G1C has two screw points, two grey clips and four plastic pegs to set a daughter board on top of the DS3800NVIA1G1C. The DS3800NVIA1G1C has one-hundred and twenty resistors. Each resistor has a different colored base and each resistor has a different set of up to five different colored bands. These bands coincide with a color code to figure out how much energy each resistor can handle. The DS3800NVIA1G1C has nineteen integrated circuits which hold the programming for the DS3800NVIA1G1C . The DS3800NVIA1G1C has two large silver diodes, three average silver diodes, three cherry diodes, two light blue diodes, thirty-six clear orange colored diodes, and five dark burgundy diodes. The DS3800NVIA1G1C has one amber LED and four cherry LEDs. The LEDs are light emitting diodes that light up as an energy current flows through them.

Please contact TurbineIndustrial for a price quote or any additional information.
