Description

The DS3800NPSJ1B1B is a PCB (printed circuit board) which was produced by GE (General Electric). This circuit board was made to be a part of the MKIV (Speedtronic Mark IV) turbine management system. Mark IV is part of the Mark turbine management series. These systems are in charge of managing efficient operations for the turbine and for protecting the turbine from dangerous conditions.

Most of the surface of the DS3800NPSJ1B1B is covered with various very small components. Many small resistors, capacitors, and diodes are placed all over the DS3800NPSJ1B1B. Many of these small resistors are blue in color and banded in stripes of different colors. Many of the resistors are also solid in color. Many of these solid resistors are blue or reddish brown. A variety of capacitors can be seen all over the DS3800NPSJ1B1B. These capacitors are silver in color. They come in a variety of sizes. A few larger capacitors can also be seen on the DS3800NPSJ1B1B. Two (2) large yellow capacitors are aligned next to each other near one of the edges of the DS3800NPSJ1B1B. One (1) large silver capacitoris located next to these yellow capacitors. Another medium-sized silver capacitoris positioned on another edge of the DS3800NPSJ1B1B. A total of five (5) integrated circuits are situated around the DS3800NPSJ1B1B. These integrated circuits are labeled with their part number which is LM148D/8838. Eleven (11) test points can be found on one of the edges of the DS3800NPSJ1B1B. These test points allow the operator to test the board to make sure it is working efficiently.
