Description

The DS3800NPIA1B1B is a PCB, or printed circuit board. This product was made by GE (General Electric). The DS3800NPIA1B1B was made to be a part of the MKIV, or Speedtronic Mark IV series. The MKIV is just one system in the Mark series. The Mark IV series is a system which was made to control gas and steam turbines.These Mark turbine control systems have been used for turbine control since the late 1960s. The Mark IV automates turbine processes while protecting the system from damage which can occur because of operating under unsafe conditions. The technologies used by the Mark systems were developed based on automation processes which have been used and perfected for many decades.

The DS3800NPIA1B1B is a daughter card, a small circuit board which may be connected to the surface of a larger board. Attaching a daughter board to a larger printed circuit board gives the board more functionality and enabling the user to have more options for operation. The DS3800NPIA1B1B daughter board is what is called a high voltage input card.

The DS3800NPIA1B1B is a small printed circuit board. On the surface of the DS3800NPIA1B1B, there are a total of twenty (20) resistors which are grey in color. Sixteen (16) of the resistors are mid sized. They are designated with the letter R, from R1 through R8 and from R11 through R18. There are also four (4) other grey resistors which are smaller in size. They are also marked with the letter R and these are named R9 through R10 and R19 through R20. There are also seventeen (17) wire links, also known as jumpers, on the DS3800NPIA1B1B.
