Description

The DS3800NHVJ1A1A is a part of the Mark IV Speedtronic series made by General Electric.The Mark IV Speedtronic series was created to control gas turbines. The DS3800NHVJ1A1A has six big black capacitors, six big silver capacitors, three average sized yellow capacitors, five little yellow capacitors, and ten little red capacitors. Each capacitor holds a diverse amount of energy in an electric field. The DS3800NHVJ1A1A has five sets of points referred to as Jumper Ports. Using the shelters provided the worker can change the energy current around the board using the shelters on the Jumper Ports. The DS3800NHVJ1A1A has six large sized dark brown resistors and two tiny pale blue resistors. The DS3800NHVJ1A1A has nearly twenty grey diodes, two small ball like diodes and two small brown diodes There are three large black boxes referred to as relays. A relay helps slow down the electrical current to a level that the DS3800NHVJ1A1A can handle. The DS3800NHVJ1A1A also has three red LEDs (light emitting diodes). Two LEDs are right next to two of the three relays. The final LED is a little lower than the final relay. Each LED with light up as an electrical current flow through it. The DS3800NHVJ1A1A has three pairs of twisted black and white wires, there is also small short white wire arches. The DS3800NHVJ1A1A also has three male terminal ports with white plastic and one male port with black plastic. These ports allow for the DS3800NHVJ1A1A to be connected to another circuit board. The DS3800NHVJ1A1A also features three oval cutouts in the board as well.
