Description

The DS3800NFMC1E1C is a component in the Mark IV series made for the control of turbines. This product is a fault finder display circuit board. The DS3800NFMC1E1C was made by General Electric.

The DS3800NFMC1E1C has many different important components. Covering a lot of space on the board are thirty-eight (38) integrated circuits. The DS3800NFMC1E1C also contains one (1) long connector port. More components or other board can be connected to the DS3800NFMC1E1C using this port. A group of nine (9) LEDs is included on the right side of the DS3800NFMC1E1C. LED is an acronym meaning light-emitting diode. When they are functioning, the LEDs are lit red. Fifteen (15) test points are lined up next to the LEDs. These test points are labeled with the initials TP and are named TP1 to TP15. Test points allow an operator to make sure that the board is working properly. Also found on the DS3800NFMC1E1C is a range of capacitors in various colors and sizes. Located near the right edge of the DS3800NFMC1E1C are two (2) medium-sized silver capacitors. Another silver capacitor which is smaller is near the upper edge of the board. The DS3800NFMC1E1C also contains many small capacitors which are covered in multi-colored bands. Also located on the DS3800NFMC1E1C are many resistors. These are smaller resistors which come in various colors and sizes. Some of these resistors are solid, while others have multi-colored bands. Lined up in rows of three and four on the left side of the DS3800NFMC1E1C are nineteen (19) round black transistors.
