The DS3800NCBA1A1B was produced by General Electric. It is part of the Speedtronic Mark IV turbine control series. The Mark systems, beginning with Mark I, have been used for many years to provide superior turbine control. The DS3800NCBA1A1B is a component circuit board.

Eight potentiometers are featured on the right side of the DS3800NCBA1A1B. Potentiometers, also known as variable resistors, are used to change the resistance of each device. The potentiometers on the DS3800NCBA1A1Bare identified with the reference designator RH, ranging from RH1 through RH8. A message reading “mount polarity bands” is written near the potentiometers. Forty-seven capacitors are located all around the DS3800NCBA1A1B. These capacitors are all numbered. Listed on the upper edge of the DS3800NCBA1A1B are the letters A through J. Two resistors are found close to the top of the DS3800NCBA1A1B board. The resistors on the DS3800NCBA1A1B are banded with multicolored stripes. The colors of these stripes symbolize the each device’s capacity for resistance. The resistors are identified with the initial R, as R20 and R21. A connector port is located on the DS3800NCBA1A1B which takes up the left border of the card. Extra parts or other boards may be attached to the DS3800NCBA1A1B with this connector port. The numbers 10 to 80 are written next to the port by tens. The letters A to Z are found all around the DS3800NCBA1A1B board.

TurbineIndustrial is dedicated to providing quality products and great customer service. All parts will be delivered enclosed in a way which will dissipate any static before the DS3800NCBA1A1B is opened by the operator.
