Description

The DS3800NBID1E1D is a bridge interface circuit board. It was made to be a component in the Speedtronic Mark IV series of turbine control. The DS3800NBID1E1D was created by General Electric.

The DS3800NBID1E1D contains 18 integrated circuits. These integrated circuits occupy much of the board and can be identified by the initial U. Many capacitors which are red, blue and silver can be found on the DS3800NBID1E1D. These capacitors can be identified by the initial C. Much of the space on the DS3800NBID1E1D is occupied by a wide range of resistors which can be identified by the initial R. There resistors all have various colored bands. Each resistor's bands indicate the resistor's capacity for resistance. The DS3800NBID1E1D has an orange LED, or light-emitting diode, in the upper left corner of the board. This diode can be identified by the initials CR and is known as CR5. There are other diodes around the board which are not light-emitting. These diodes can also be identified by the initials CR as well. In a line at the top of the board are 22 test points identified by the initials TP. The DS3800NBID1E1D contains two resistor networks which can be identified by the initials RN. There are known as RN1 and RN2. Featured along the lower edge of the DS3800NBID1E1D is a long connector port. With this port, additional boards or parts can be connected to the board.
