DS3800HXRC1F1C
DS3800 GENERAL ELECTRIC PRINTED CIRCUIT BOARD RECEIVER 6 SERIES
Contact
Us!
Warranty: 3 Year Warranty
Manuals & Datasheets: Request via Email
DS3800HXRC1F1C
DS3800 GENERAL ELECTRIC PRINTED CIRCUIT BOARD RECEIVER 6 SERIES
- 4.50 (2)
- Click a star to rate this product
Availability:
In Stock Ships Today
Description
The DS3800HXRC1F1C from GE is a PCB created as part of the Mark IV line. The Mark IV has been created specifically to be a steam and gas turbine control system and can function as a monitor for turbines as well as for their auxiliaries. It can sequence turbines and auxiliaries for their start-up and cool down procedures.
The DS3800HXRC1F1C is used as a Series 6 receiver. It is also a motherboard for the DS3800HXRC1F1C, another PCB in the Mark IV line. The DS3800HXRC1F1C can be connected to the DS3800HXRC1F1C via a ribbon cable which connects to a cable port located in the middle of the DS3800HXRC1F1C. This extends the power of the motherboard by giving it access to the multiple integrated circuits and 18 jumper switches located on the auxiliary board.
The DS3800HXRC1F1C has the following specs:
-
It has been factory drilled. Two clips have been attached to two corners.
-
It is marked on the upper edge. It is also marked 6BA03.
-
It has four connectors to easily interact with other boards (including the ribbon connector mentioned above.) It also has one female connector (218A44553-1) on its left edge, and two male connectors on the opposite short edge.
-
It has two transistors. These are placed near the lower left of the PCB.
-
The DS3800HXRC1F1C has 48 integrated circuits.
-
It has been designed with resistor networks, jumper switches, and metal film (ceramic covered) resistors.
Manuals and data sheets for the DS3800HXRC1F1C were originally provided by GE as part of ongoing technical support. Installation guidelines for the DS3800HXRC1F1C can be found within these publications.
Purchase
Please give us a call or send us an email for pricing on New Surplus and Reconditioned replacements that we have in our inventory. Our lead times are short, stock is excellent, and pricing is competitive. We hope to be your go-to supplier for all GE Turbine replacement boards and controls.
Exchange
We conveniently offer an exchange program that allows you to recycle your old board and receive an up-front discount on a replacement. Please ask about our exchange credit program if you have a defective board to exchange with the purchase of a new or reconditioned replacement. We ask that the defective board is sent in within 30 days of the purchase.
Repair
We offer repair on most GE Turbine boards we sell. Although we usually have replacements available, we recognize that customers may prefer to have their board repaired. Our repair program allows us to offer a lower cost alternative to replacement.
