DS3800HSQD1F1D
GE FANUC SPEEDTRONIC SEQ ASSEM. MODULE DS3800HSQD1F1D
Contact
Us!
Warranty: 3 Year Warranty
Manuals & Datasheets: Request via Email
DS3800HSQD1F1D
GE FANUC SPEEDTRONIC SEQ ASSEM. MODULE DS3800HSQD1F1D
- 5.00 (2)
- Click a star to rate this product
Availability:
In Stock Ships In 3-5 Days
Description
The GE Low HP Sequence Board DS3800HSQD1F1D is engineered with 1 hole in each corner to insert screws to secure the board in the drive. The GE Low HP Sequence Board DS3800HSQD1F1D also is populated with 2 40-pin connectors and 1 20-pin connector with retention latches to secure the ribbon cables. The board is also populated with a 50-pin connector and 1 20-pin connector on the surface of the board. The board also is populated with 1 erasable programmable read-only memory (EPROM) module and 1 amber indicator LED and 8 red indicator LEDs.
The retention levers on the 2 40-pin connectors ensure that the ribbon cables can not be accidentally disconnected. However, they do require some additional information when you connect them or disconnect them. To connect a ribbon cable into the connector with a retention latch, first move the retention latch to the open position and align the connector on the ribbon cable. Use your thumbs to press the connector into position and inspect the connection. If you see spaces between the connectors, press the ribbon cable connector again to ensure a complete connection. Then, lower the retention latches into place.
To remove a ribbon cable, first swing the retention latch free from the connector. Use 1 hand to remove the ribbon cable from the connector. Only pull the ribbon cable out by holding the connector and not by tugging on the ribbon cable. This might damage the ribbon cables and break the control signal connections.
Purchase
Please give us a call or send us an email for pricing on New Surplus and Reconditioned replacements that we have in our inventory. Our lead times are short, stock is excellent, and pricing is competitive. We hope to be your go-to supplier for all GE Turbine replacement boards and controls.
Exchange
We conveniently offer an exchange program that allows you to recycle your old board and receive an up-front discount on a replacement. Please ask about our exchange credit program if you have a defective board to exchange with the purchase of a new or reconditioned replacement. We ask that the defective board is sent in within 30 days of the purchase.
Repair
We offer repair on most GE Turbine boards we sell. Although we usually have replacements available, we recognize that customers may prefer to have their board repaired. Our repair program allows us to offer a lower cost alternative to replacement.
