Description

The DS3800HRMD1C1B is featured in the Mark IV Speedtronic line and is constructed by GE (General Electric). This board contains over one-hundred resistors. These resistors have numerous uses, they alter signals, reduce energy flow amid others. There are thirty-five orange dyed diodes, three metallic diodes, a dark-colored diode and a ruby-colored diode, and six light blue diodes. The DS3800HRMD1C1B also contains twenty pairs of metal spines called Jumper ports. These Jumper ports come with several black covers to be relocated around the various ports to regulate how the energy flows throughout the board. There three slim gold capacitors and one slim dark blue capacitor. There is also a tube-shaped gold capacitor and three tiny black semi-circle capacitors. The DS3800HRMD1C1B has a combination of forty-four EPROMs and EEPROMs. These mechanisms hold the platforms that permit the DS3800HRMD1C1B to function. If the DS3800HRMD1C1B requires a revision, the DS3800HRMD1C1B would be improved through the EPROMs minuscule port where the new data is installed. If additional coding space is desired an extra EPROM or EEPROM may be added, in the area labeled “SPARE”. The DS3800HRMD1C1B has a little switch in a small plastic cover. The DS3800HRMD1C1B has a connector (female) for a wiring harness, along one side and two smaller wiring harness connectors (male) on the opposite edge. One male connect is littler than the other. The DS3800HRMD1C1B can also be easily connected to other boards a pair of clips and with a small number of screws.

TurbineIndustrial would be privileged to be your go-to for all your needs. Give TurbineIndustrial a phone call today.
