Description

The GE Parallel Line Buffer Board DS3800HPBC1A1B is designed for quick installation in the drive. The board features a modular connector on 1 end and retention levers on the other end. The GE Parallel Line Buffer Board DS3800HPBC1A1B also is populated with 1 red indicator LEDs and 2 amber LED which are visible from the front of the board. The board also is populated with 3 jumpers, and multiple capacitors.

Another component on the board is a transistor to transistor logic (TTL) device. It serves as the interface logic between integrated circuits.

When the GE Parallel Line Buffer Board DS3800HPBC1A1B is replaced by a servicer, it is important to follow some basic safety guidelines to maintain a safe working environment. The drive is a powerful device with high-voltage current operating the motor, other moving parts, and the many boards and other devices. For this reason, when the servicer replaces the board, before starting the procedure, the surrounding area must be inspected for hazards. Also, actions must be taken to ensure the area is safe to work in.

The floor around the drive must be free of dirt, dust, and clutter. Clear away any equipment, tools, and other items. If 2-wire extension cords are being used to power devices, remove them and replace the cords with 3-wire extension cords. This is to avoid a shock hazard. If the floor is wet and has puddles of water on it, use rags to dry the floor of all moisture. If condensation is a recurring issue, install equipment to keep the air dry to prevent the formation of condensation.
