DS3800HHTB1D1D
DS3800 GE DRIVE SYSTEMS GAS TURBINE CONTROL TRANSMITION CARD
Contact
Us!
Warranty: 3 Year Warranty
Manuals & Datasheets: Request via Email
DS3800HHTB1D1D
DS3800 GE DRIVE SYSTEMS GAS TURBINE CONTROL TRANSMITION CARD
- 3.00 (1)
- Click a star to rate this product
Availability:
In Stock Ships Today
Description
This is a circuit card by GE created for the Speedtronic Mark series. The DS3800HHTB1D1D is a component of the Mark IV series. This system has developed as a direct result of years of refinement of the earliest Mark systems of controls for turbines. Ever since the 1960s, when the Mark I series was created, the Mark series has been responsible for all parts of safety and and operating turbines. The Mark IV system is a result of decades of innovating technologies important for the automation of circuits.
DS3800HHTB1D1D board is occupied by 34 integrated circuits. Every integrated circuit has a variety of electronic devices such as capacitors, resistors and diodes all on one small device. There are a series of small resistors located on the board which are striped, as well as a series of small resistors. There are a variety of small capacitors which are scattered around the board. There are three light-emitting diodes on the side of the card which have indicator lights. Under the three diodes that have indicator lights, there are 4 test points which can alert the operator about any problems with the card. A jack connector port takes up almost the entirety of the left border of the card. Silver diodes are situated on each part of the left side of the board. DS3800HHTB1D1D, the full product name, is stamped on one of the borders of the circuit card.
The product will be sent packaged in a way which will dissipate any static energy that accumulates during shipping for the safety of the operator.
Purchase
Please give us a call or send us an email for pricing on New Surplus and Reconditioned replacements that we have in our inventory. Our lead times are short, stock is excellent, and pricing is competitive. We hope to be your go-to supplier for all GE Turbine replacement boards and controls.
Exchange
We conveniently offer an exchange program that allows you to recycle your old board and receive an up-front discount on a replacement. Please ask about our exchange credit program if you have a defective board to exchange with the purchase of a new or reconditioned replacement. We ask that the defective board is sent in within 30 days of the purchase.
Repair
We offer repair on most GE Turbine boards we sell. Although we usually have replacements available, we recognize that customers may prefer to have their board repaired. Our repair program allows us to offer a lower cost alternative to replacement.
