DS3800HHRB
DS3800HHRB GENERAL ELECTRIC RECEIVER BOARD
Contact
Us!
Warranty: 3 Year Warranty
Manuals & Datasheets: Request via Email
DS3800HHRB
DS3800HHRB GENERAL ELECTRIC RECEIVER BOARD
- 5.00 (1)
- Click a star to rate this product
Availability:
In Stock Ships Today
Description
The DS3800HHRB was made by General Electric. This printed board is part of the Speedtronic Mark IV series, a control series for gas turbines. The DS3800HHRB is a highway receive board.
The DS3800HHRB features a long connector port positioned vertically along the edge of the board. Lined up to the right of the connector port are labels in the numbers 10 through 80 in steps of ten. Located around the board are 25 integrated circuits. On the upper half of the DS3800HHRB are 6 jumper pins that have blue jumpers. On one edge of the printed board is a diode with an indicator light that is red. Displayed around the printed board are several small striped resistors which which are white and blue and are named with the letter R. On the right side of the board, there is a metal wire which is silver connected to an integrated circuits. Located on both the top and bottom sides of the left portion of the printed board are 2 blue capacitors. Beside the blue capacitors are two bigger silver capacitors. There are 4 test points marked with TP lined up on the right-hand side of the circuit board. Featured on the top of the printed board are the letters A to H.
The Mark IV system was developed by General Electric and was based on its predecessor Mark I and Mark II systems.The DS3800HHRB highway receive circuit board will be sentin a bag which gets rid of any energy before handling by the operator. Technical support for the part would be handled by GE.
Purchase
Please give us a call or send us an email for pricing on New Surplus and Reconditioned replacements that we have in our inventory. Our lead times are short, stock is excellent, and pricing is competitive. We hope to be your go-to supplier for all GE Turbine replacement boards and controls.
Exchange
We conveniently offer an exchange program that allows you to recycle your old board and receive an up-front discount on a replacement. Please ask about our exchange credit program if you have a defective board to exchange with the purchase of a new or reconditioned replacement. We ask that the defective board is sent in within 30 days of the purchase.
Repair
We offer repair on most GE Turbine boards we sell. Although we usually have replacements available, we recognize that customers may prefer to have their board repaired. Our repair program allows us to offer a lower cost alternative to replacement.
