Description
The GE Fish Processor Board DS3800HFPE1D1B features a modular connector for attachment to a drive and retention levers to hold the board in the drive. The GE Fish Processor Board DS3800HFPE1D1B also is populated with 3 jumpers, and multiple capacitors. The board has 1 34-pin connector that is accessible from the front of the board. It also is populated with test points and 1 40-pin connector on the surface of the board.
Another component on the board is a transistor to transistor logic (TTL) device. It serves as the interface logic between integrated circuits.
The GE Fish Processor Board DS3800HFPE1D1B is populated with 1 40-pin connector on the surface of the board. The ribbon cable you attach to it must be connected before you install the board in the board rack. One other 40-pin connector is located on the edge of the board and can be attached after the board is installed in the rack.
To install the board, locate the 40-pin ribbon cable you want to attach to the board. Place the board on a clean surface near the drive and connect the ribbon cable to the 40-pin connector. The board must be installed at the top of the board rack so that the ribbon cable does not interfere with the other boards. Slide the board into the rack and route the ribbon cable so that the free flow of air around the board rack is not interrupted. Use your thumbs to press the board into the modular connector at the back of the board rack. Close the retention levers.
