DS3800HDPA1A1A
GENERAL ELECTRIC MARK 4 INTERFACE SPEEDTRONIC DS3800HDPA1A1A
Contact
Us!
Warranty: 3 Year Warranty
Manuals & Datasheets: Request via Email
DS3800HDPA1A1A
GENERAL ELECTRIC MARK 4 INTERFACE SPEEDTRONIC DS3800HDPA1A1A
- 4.00 (1)
- Click a star to rate this product
Availability:
In Stock Ships Today
Description
The DS3800HDPA1A1A is a circuit board made by GE for display panels for the Speedtronic Mark IV series of turbine controls.
A display panel, otherwise known as a Human Machine Interface enables the user to interface with the turbine system. Display panels enable the user to more carefully monitor the operations of the turbine system. The ability to monitor operations aids productivity for the user and informs the user to any problems with the functioning of the turbine.
The DS3800HDPA1A1A circuit board features two blue connectors positioned on the left side of the board. The connector ports are marked with the labels JA and JB in dark letters. The ports are also marked with their part name in dark letters. There is another small blue jack connector port positioned on the top side of the board marked JC in dark letters. The board has fifteen dark diodes that are topped with red lights. These diodes are marked with the labels CR1 to CR15 in dark letters. The circuit board has eight dark switches marked with the labels SW1 to SW8 in dark letters. On the circuit board there are also eighteen striped and resistors with different colors on the board marked with the labels R1 to R18 in dark letters. The circuit board contains a black integrated circuit.
The DS3800HDPA1A1A display panel board is sent in a bag which gets rid of the static energy before the part is handled by the user. Any troubleshooting or technical support would be provided by GE (General Electric), the manufacturer.
Purchase
Please give us a call or send us an email for pricing on New Surplus and Reconditioned replacements that we have in our inventory. Our lead times are short, stock is excellent, and pricing is competitive. We hope to be your go-to supplier for all GE Turbine replacement boards and controls.
Exchange
We conveniently offer an exchange program that allows you to recycle your old board and receive an up-front discount on a replacement. Please ask about our exchange credit program if you have a defective board to exchange with the purchase of a new or reconditioned replacement. We ask that the defective board is sent in within 30 days of the purchase.
Repair
We offer repair on most GE Turbine boards we sell. Although we usually have replacements available, we recognize that customers may prefer to have their board repaired. Our repair program allows us to offer a lower cost alternative to replacement.
