Description

The GE Circuit Board DS3800DSFC1A1A is 2 inches in height and 3 inches in length. The board features 1 trimmer resistor, multiple capacitors, and 5 jumpers. The GE Circuit Board DS3800DSFC1A1A also is populated with 2 single-pin connectors and 10 resistors embedded on the board.

When the board is serviced or replaced, only a qualified servicer can perform the task. This is because the drive contains high-voltage current that can cause serious harm. Electric shock can occur as well as serious electric burns. Another hazard is the risk of injury from the powerful motor and other moving parts. For this reason, the technician must be aware of the dangers and be prepared to avoid them. Before starting any procedure, the technician must observe the surrounding area and note any moisture on the floor. Clear the floor of any moisture and if it is a continuing problem, install air drying equipment to maintain a dry floor. If oil or grease is present, remove it with detergents and when finished make sure the floor is dry.

Also check for ungrounded electric cords and remove them from the area. These can cause an electric shock hazard. The technician must also locate all emergency shut off devices connected to the drive. This might require consulting with an engineer or electrician who is familiar with the drive installation. If an accident occurs while performing a replacement or service on the drive, the emergency shutoff can remove all power from the drive and reduce the harm to individuals.
