Description

The GE Circuit Board DS3800DOCA1A1A features 4 trimmer resistors and 13 single-pin connectors. The GE Circuit Board DS3800DOCA1A1A also is populated with 4 terminals for attaching additional components and 4 resistors embedded on the board.

The GE Circuit Board DS3800DOCA1A1A is 1 of several boards that are installed in the drive and maintaining the interior temperature of the drive below a threshold is very important for several reasons. Excessive heat can lead to early failure of the board and other components. This increases maintenance costs and reduces productivity when the drive is offline for repair. Another problem is that increased heat can lead to intermittent errors that are difficult to diagnose and resolve.

To avoid these problems, you must plan the installation with several factors in mind. The drive is installed on a wall or other vertical surface and is often in a room with many other drives and other equipment. All the devices generate heat that must be managed. Plan the installation of the drive so that a minimum amount of the room is allowed for the drive. This allows air to flow freely through the drive. The air enters the drive from the bottom vents and exits from the top vents. The air removes heated air from the interior of the drive and keeps the drive components cool.

If the air temperature in the drive reaches a threshold, the drive will automatically shutdown. This shutdown is referred to as an over temperature trip condition. It saves the drive from damage caused by excessive heat.
