Description

The DS3800NVPA1E1B is part of General Electric’s Mark IV Speedtronic line. The DS3800NVPA1E1B has fifteen teal blue diodes, and around ten small yellow diodes. The diodes control the direction of the energy by allowing the energy to flow in only one direction. The DS3800NVPA1E1B has three amber colored LED or light emitting diodes which illuminate as energy flows through it. The DS3800NVPA1E1B also has over thirty resistors. The resistors are identifiable by the multiple colored rings around the outside. These rings also coincide with a code to identify how much energy the resistors can restrict. The DS3800NVPA1E1B also has a combination of twenty-two EPROM and EEPROMs. The EPROM and EEPROMs are also known as integrated circuits. The EPROM is a re-programmable integrated circuit that holds the data for the DS3800NVPA1E1B to work. The EEPROMs come pre-programmed integrated circuit that also hold the data for the DS3800NVPA1E1B to function as well but this one cannot be changed. The DS3800NVPA1E1B also has two transistors, one is a small black transistor, the other is a small silver circular transistor. The DS3800NVPA1E1B also has a small blue male terminal port that allows the DS3800NVPA1E1B to attach to other circuit boards around it. The DS3800NVPA1E1B is also a motherboard that has four pegs to place a daughter board on. The DS3800NVPA1E1B has six slim yellow capacitors and three larger yellow capacitors. A capacitor is used to store extra energy in its electrical field for the circuit board to use at another time.

For any additional information please contact the professional staff at TurbineIndustrial.
