Description

The DS3800NCCB1H1F is an auxiliary circuit board that was created by General Electric. The DS3800NCCB1H1F board was made to be a component in the Speedtronic Mark IV turbine control series.

Resistors with several different colors and patterns cover the DS3800NCCB1H1F. Each resistor’s resistance capability is represented by the different colors of the bands. Throughout the board are also many black diodes. Yellow capacitors in different sizes can also be found on the DS3800NCCB1H1F. Eighteen integrated circuits are located on the DS3800NCCB1H1F. Tiny circuit parts like capacitors, diodes, and resistors among other things are found on these integrated circuits. Four resistor networks are placed on the DS3800NCCB1H1F. A line of resistors is held inside each resistor network. The sum of the resistances of all of the resistors is equivalent to the resistance of the resistance network. Four light-emitting diodes are located on one end of the DS3800NCCB1H1F. The light-emitting diodes, also known as LEDs, glow orange when they are lit. Between the LEDs, there is a line of fifteen test points. These test points can be used in testing the card to ensure that it is functioning properly. On one edge of the DS3800NCCB1H1F board, there is a large connector port. Another small connector port is situated in the middle of the DS3800NCCB1H1F which can also be used to connect parts to the board. More components can be attached to the board using these ports. In addition to all of these parts, there are two small transistors located on the DS3800NCCB1H1F.

TurbineIndustrial always ships parts wrapped in anti-static packaging which eliminates static energy accumulated during shipping.
