DS3800NBIC1J1G
GENERAL ELECTRIC INTERFACE BOARD DS3800NBIC1J1G
Contact
Us!
Warranty: 3 Year Warranty
Manuals & Datasheets: Request via Email
DS3800NBIC1J1G
GENERAL ELECTRIC INTERFACE BOARD DS3800NBIC1J1G
- 4.50 (2)
- Click a star to rate this product
Availability:
In Stock Ships Today
Description
DS3800NBIC1J1G is a bridge interface circuit card made for the Speedtronic Mark IV series for turbine control. The DS3800NBIC1J1G was produced by GE (General Electric).
Featured on the DS3800NBIC1J1G are 26 integrated circuits which all have many small components. Twelve transistors are labeled on the board from Q4 to Q15. Designated as Q1 to Q3 are three more transistors adding up to a total of 15. On one side of the DS3800NBIC1J1G is a connector port on one side that lets an operator attach additional boards or more components to the DS3800NBIC1J1G. Featured on the DS3800NBIC1J1G is a range of yellow, silver, and blue capacitors. Several resistance networks are located on the DS3800NBIC1J1G. Within each resistance network is a group of resistors. Adding together the resistances of each individual resistor equals the total resistance of each resistance network. A range of others resistors in addition to the resistance networks is on the DS3800NBIC1J1G. Various colored bands signify the resistance capacities of each resistor. Blue and black diodes can also be seen on the DS3800NBIC1J1G. Seen on the DS3800NBIC1J1G is a group of jumper pins featuring blue jumpers. With these jumpers, users can connect two pins, which makes changes to the board. Twenty-four test points are lined up on one side of the DS3800NBIC1J1G. These test points enable the DS3800NBIC1J1G to be tested for any issues. Also seen on the DS3800NBIC1J1G is a light-emitting diode, or LED.
GE should be contacted in the event any troubleshooting or technical support for the DS3800NBIC1J1G is needed.
Purchase
Please give us a call or send us an email for pricing on New Surplus and Reconditioned replacements that we have in our inventory. Our lead times are short, stock is excellent, and pricing is competitive. We hope to be your go-to supplier for all GE Turbine replacement boards and controls.
Exchange
We conveniently offer an exchange program that allows you to recycle your old board and receive an up-front discount on a replacement. Please ask about our exchange credit program if you have a defective board to exchange with the purchase of a new or reconditioned replacement. We ask that the defective board is sent in within 30 days of the purchase.
Repair
We offer repair on most GE Turbine boards we sell. Although we usually have replacements available, we recognize that customers may prefer to have their board repaired. Our repair program allows us to offer a lower cost alternative to replacement.
