Description

The DS3800HPTN1J1H is for the Speedtronic Mark IV series produced by GE (General Electric).The upper edge of the board has a label A through H. All components on the DS3800HPTN1J1H board are identifiable with white alphanumeric markings. There are four yellow long points with a cover on the right. There are over ten yellow points on the left. There are over ten average size black resistors and over ten blue resistors. The DS3800HPTN1J1H has six elongated resistors that have a power rating of eighteen ohms with a variance of five percent up or down and are also has a ten-watt rating as well. The DS3800HPTN1J1H has three LEDs one is amber yellow and two are red. The DS3800HPTN1J1H has several capacitors. There are five small capacitors, one average size capacitor, and three big capacitors. There over twenty diodes in an assortment of colors. The DS3800HPTN1J1H has two transformers next to each other. Transformers are used to handover electrical energy amongst multiple circuits by means of electromagnetic induction. To the right of the transformers are four narrow spines. There are five small round transistors and three larger round transistors. Transistors are applied to assist in intensifying or swapping an electrical power or electronic signals. There is a red and orange circular choke which keeps energy in a magnetic field it makes when an electric current flows through it. There is also a clear fuse. The DS3800HPTN1J1H has a pair of clasps and a few places to insert screws to help attach the board in place.
